• GENERAL FEATURES
  Method of analysis:	Nitrogen determination according to Dumas method (combustion)
  Duration of analysis:	3/4 minutes
  Detector:	Innovative TCD autocalibrating
  Sample weight:	max 1g
  Autosampler capacity:	up to 4 discs, 30 positions each
  Reproducibility (RSD):	< 0.5% for EDTA standards (9.57%N)
  Recovery:	> 99.5%
  Carrier gas:	Helium or Argon
  Detection limit:	0.001 mg N, with Helium 0.01 mg N, with Argon
  Carrier gas (He/Ar):	purity 99.999% (grade 5.0)
  Oxygen (O2):	purity 99.999% (grade 5.0)
  Compressed air or Nitrogen (N2):	purity 99.6 % (oil and water free)
  Carrier gas (He/Ar) pressure:	2 bar
  Oxygen (O2) pressure:	2 bar
  Interfaces:	USB; RS232
  Power:	1400 W
  Power supply:	230 V / 50 - 60 Hz
  Weight:	54 kg / 119 lb
  Dimensions (WxHxD):	655x510x410 mm (H 690 mm with autosampler) 25.8x20.1x16.1 in (H 27.0 in with autosampler)

Exceptional Versatility

• Can operate with Argon or Helium as carrier gas
• Preinstalled methods selectable in an instant
• Controllable from PC with DUMAsoft™ software
• Powerful, clear and detailed reporting software
• Data storable in multiple formats for LIMS or PC

High Productivity

• Flash determination of nitrogen & protein content
• Automated analysis of preloaded samples (117 positions)
• Totally unsupervised operation
• Results produced 24/7/365

High Performance

• Unmatched LOD (0.001 mg N (using He) - 0.01 mg N (using Ar))
• RSD less than 0.5% with EDTA standard
• Conforms to Good Laboratory Practice standard
• Leak tests (zone or total) ensure optimum performance

Economical Operation

• LoGas™ TCD with no reference gas required
• Exceptionally low cost per analysis
• Premium quality consumables
• Low energy consumption
• Lowest operator costs

Environmentally Friendly

• Minimum possible waste & residues
• Optimized life of consumables
• Incorporates TEMS™ technology*


  *Saving Time, Energy, Money & Space
