Analog Output Functional Mode

Linear, Logarithmic, Bi-linear, PID

Analog Outputs

Two (Five with optional expansion module) 0/4 to 20 mA isolated current outputs, max 550 Ω, Accuracy:+/- 0.1% of FS (20mA) at 25C, +/- 0.5% of FS over -20C to 60C range

Communication

MODBUS RS232/RS485, PROFIBUS DPV1, HART optional

Communication Capabilities

2x 4-20 mA Out

Conduit Openings

1/2 " NPT Conduit

Dimensions (H x W x D)

144 mm x 144 mm x 181 mm

Display

Graphic dot matrix LCD with LED backlighting, transreflective

Display Resolution

240 x 160 pixels

Display Size

48 x 68 mm

Electrical Certifications

EMC
CE compliant for conducted and radiated emissions:
- CISPR 11 (Class A limits)
- EMC Immunity EN 61326-1 (Industrial limits)
Safety
cETLus safety mark for:
- General Locations per ANSI/UL 61010-1 & CAN/CSA C22.2. No. 61010-1
cULus safety mark
- General Locations per UL 61010-1 & CAN/CSA C22.2. No. 61010-1

Enclosure Rating

IP66 / NEMA 4X

Manual Languages

Bulgarian, Chinese (PRC), Croatian, Czech, Danish, Dutch, English, Estonian, Finnish, French, German, Greek, Hungarian, Italian, Japanese, Korean, Lithuanian, Polish, Portuguese (Brazil), Portuguese (Portugal), Romanian, Russian, Slovak, Slovenian, Spanish, Swedish, Thai, Turkish

Material Enclosures

Polycarbonate
Aluminium (powder coated)
Stainless Steel

Mounting Configurations

Wall
Pole
Panel Mounting

Operating Temperature Range

-20 to 60 °C at 0 to 95% RH (non-condensing)

Power Requirements (Hz)

50 - 60 Hz

Power Requirements (Voltage)

100 - 240 VAC

Relay: Operational Mode

Primary or secondary measurement, calculated value (dual channel only) or timer/scheduler

Relay Functions

Alarm, Timer/Scheduler, Feeder Control, Pulse Width Modulation, Frequency, System Alarm

Relays

Four electromechanical SPDT (Form C) contacts, 1200 W, 5 A

Security LevelsDigital

2

Sensor Input #1

PH/ORP

Sensor Input #2

PH/ORP

Storage Conditions

-20 °C to 70 °C

Warranty

1 year

Weight

3.75 lbs. (1.70 kg)
