Accuracy

5 % of measured value +0.2 mg/L(with standard solutions) NH₄–N

Cable Length

10 m / 32.8 fixed cable at sensor

Cable Length 2

10 m fixed cable at sensor, available up to 100 m

Calibration Method

With CARTRICAL plus technology: automatic import of factory calibration data from cartridge to probe by RFID; 1 and 2 point matrix correction

Controller Compatibility

sc 200, sc 1000

Data Transfer

current output, relays and bus communication via sc controller

Diameter

84.5 mm

Flow

< 4 m/s max.

Installation Angle

45 ° ± 15 ° (vertical in flow direction)

Length

320 mm

Lower Limit of Detection (LOD)

0.2 mg/L NH₄–N

Material

Cartridge: Stainless steel (1.4571), PVC, POM, ABS, NBR

Measurement Method

Potentiometric ion-selective measurement

Measurement Range

± 5 % 0.2 mg/l (with standard solutions) NH₄-N
0.2 mg/l NH₄-N (with standard solutions)

Measuring Interval

Continuous

Operating Temperature Range

-4 to 113 °F

Parameter

NH₄-N

pH Range

5 to 9 pH

Process Connection

1 inch thread

Protection Class

IP68

Range

0 to 1000 mg/L NH₄–N

Repeatability

± 5 % of the measured value + 0.2 mg/L NH₄-N

Reproducibility

± 5 % of the measured value + 0.2 mg/L NH₄-N

Response Time

< 3 min

Sample Pressure

0.3 bar max.

Sample Temperature

2 to 40 °C (35 to 104 °F)

Sensor Cartridge

With CARTRICAL plus technology: compact housing containing calibrated electrodes for ammonium, potassium, reference system and temperature sensor, all calibrated to each other; typical lifetime six months

Sensor Immersion Depth

1.0 - 10 ft

Storage Conditions

5 to 40 °C (41 to 104 °F) sensor cartridge

Weight

5.25 lbs. (2.38 kg)
